Lopolight 3nm 112,5° Port Sidelight With 2.5 Metre Cables

Description

New generation.

LED (Light Emitting Diode) navigation light.

Unique and precise definition of light angles.

Rugged and unbreakable: Precision machined anodised aluminium housing protects the LED’s and electronics.

Completely waterproof and vibration proof: Interior is fully filled and sealed with special potting resin.

Waterproof to IP 68+ (submersible).

Low power consumption – 70 to 90% less than traditional navigation lights.

Full brightness with input voltages ranging from 10 to 32 Volts.

All Lopolights have been tested several times during production, a total of more than 24 hours.

Easy to install, adaptor and screws included (when applicable).

Approvals: Worldwide type approval (please refer to certificates on Lopolight.com)
Included in package: 1 Navigation light, precabled with 2.5 metres of marine grade cable, 2 Mounting screws (M6 * 8 mm), Installation guide
Materials: Anodised aluminum 25µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane.
Supply voltage: 10,0 – 32,0 VDC
Power consumption: 2,0 Watt, Current @ 12 VDC: 152 mA: Current @ 24 VDC: 95 mA
Light colours: Red
Intensity: >15cd
Visibility: (@K=0.8)3 nm
Number of LED's: 1 / 1
Suggested feed cables: 12 VDC: 2 x 0,50 mm2 24 VDC: 2 x 0,50 mm2
Vessel size: Above 50 metre (164 feet)
Mounting: Vertical
Product Code:NL301-102ST
