Lopolight 3nm 225° Masthead With Decklight – 15 Metre Cable

Description

New generation.

LED (Light Emitting Diode) navigation light.

Unique and precise definition of light angles.

Rugged and unbreakable: Precision machined anodised aluminium housing protects the LED’s and electronics.

Completely waterproof and vibrationproof: Interior is fully filled and sealed with special potting resin.

Waterproof to IP 68+ (submersible).

Low power consumption – 70 to 90% less than traditional navigation lights.

Full brightness with input voltages ranging from 10 to 32 Volts.

All Lopolights have been tested several times during production, a total of more than 24 hours.

Easy to install, adaptor and screws included (when applicable).

Approvals: Worldwide type approval (please refer to certificates on Lopolight.com)
Included in package: 1 pc. Navigation light w. deck light, pre-cabled with 15m marine grade cable, 4 pcs. Mounting screws (M6 x 8 mm), Installation instructions
Materials: Anodised aluminum 25µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane.
Supply voltage: 10,0 – 32,0 VDC
Power consumption: 2,9 Watt, Current @ 12 VDC: 232 mA: Current @ 24 VDC: 127 mA, Decklight: 6 Watt
Light colours: White
Intensity: >15cd
Visibility: (@K=0.8)3 nautical miles
Number of LED's: 2 / 3
Suggested feed cables: 12 VDC: 2 x 0,25 mm2; 24 VDC: 2 x 0,25 mm2
Vessel size: 12 – 20 meter (39,4 – 65,6 feet)
Mounting: Vertical
Product Code:NL201-011DLX 15M
