Description
The Quick DH4 2024D vertical windlass is suitable for boats from 15 – 20 meters (49 – 66 ft) and is supplied with a contactor unit and aluminium handle as standard. Its base is constructed in anodized aluminium in hard oxide, making it extremely durable.
rr
This windlass features a 12mm gypsy which is suitable for 13mm DIN 766, 12mm ISO and 7/16″ G4 chain, as well as 3/4″ (19mm) rope (PLEASE NOTE these values refer to a three-strand polyester rope with a rope/chain splice manufactured with the ‘Slim Splice Quick®’). This DH4 2024D model also features a drum.
rr
This product consists of windlass (on deck unit and motor gearbox), contactor unit, base gasket, drill template, handle, bolts and screws (for assembly), user’s manual and conditions of warranty.
rrrr
Key Features
rrrrrrrr
Vertical windlass
rr
Base in Anodised aluminium in hard oxide
rr
Rope and chain on a single gypsy
rr
Integrated sensor and magnet for chain counter
rr
Manual Free-Fall system
rr
Emergency manual lift system
rr
Supplied with pressure lever
rr
Inspection lid
rr
IP66 watertight motor
rr
Anodised aluminium gearbox
