Raymarine Quantum Q24C 18″ Radar & 10m Power Cable

Description

Product Overview



Raymarine Quantum Q24C 18″ Radar & 10m Power Cable | E70210

Raymarine Quantum is a compact, high-performance solid-state marine radar featuring CHIRP pulse compression technology. Setting a new standard for radar imaging, Quantum delivers superior radar target recognition on both long and extremely short ranges. Integrated Wi-Fi and thin cabling simplify installation plus Quantum’s energy-efficient and lightweight design provides safe radiated emissions and substantially reduced power consumption.

Choose Quantum for excellent target recognition and solid-state radar performance or step up to Quantum 2 with Doppler collision avoidance technology.

Specifications:
• Dimensions: Diameter | Height: 541.0 mm | 209.5 mm
• Weight : 5.6 kg
• Supply voltage: Either 12 V dc or 24 V dc nominal
• Operating voltage range: Minimum: 10.8 V dc | Maximum: 31.2 V dc
• Power Consumption: Transmit mode (maximum): 17 W | Standby mode: 7 W | Sleep mode (applies only to radars connected via Wi-Fi): 2 W
• Waterproofing : IPX6
• Operating temperature range: -10°C to +55°C
• Storage temperature range: -25°C to +70°C
• Additional storage conditions : Store upright; do not block vents on underside
• Humidity: Up to 95% at 35°C
• Maximum wind speed : 100 kts
• Range scales: 1/16, 1/8, 1/4, 3/8, 1/2, 3/4, 1, 1.5, 2, 3, 4, 6, 8, 12, 16, and 24 nautical miles

In the Box:
• Quantum Radome
• 10 m (32.8 ft.) Power cable
• M8 mounting bolts with spring washers and flat washers x4
• Documentation
